PCB

Description

Printed circuit board (PCB)

PLEASE NOTE
Originally there where different PCB’s supplied for various production batches. – those with 30/50w on the ID plate, production models marked as 180w and finally the last batch that carried the letter “C” at the start of the serial number. Since 1st October 2009 the PCB was standardised to fit all models and ages. The current PCB is supplied as a complete assembly, which includes the re-set switch, a black switch, a yellow condenser, a green NTC resistor (NTC-Widerstand) and on the underside a black rounded capacitor. The re-set switch is the only item that can be currently purchased separately; all other parts are only available as part of the complete PCB.

Part number: 89500.510

See parts diagram – body assembly – item D
